ONN-M2S IP65 Adjustable COB Machine Work Light Multi Angle Articulated Arm

Certification : CE ROHS FCC

Power : 5w/7.5w

Model Number : ONN-M2

Input Voltage(V) : AC/DC 12/24V, AC220V

Price : $35-39

Application : Workshop

Supply Ability : 300pcs 8-10 working days

MOQ : 1

Delivery Time : 5-8 work days

Warranty(Year) : 2-Year

Payment Terms : T/T

Brand Name : ONN

Color Temperature(CCT) : 1.6000-6500K 2.4000-450K 3.2800-3200K

Packaging Details : 12pcs/carton, 57*35*46cm, NW16kg, GW18kg

Place of Origin : Guangdong, China

IP Rating : IP65

Contact Now

ONN-M2S IP65 Adjustable COB Machine Work Light | Multi-Angle Articulated Arm

Product Overview

ONN-M2S heavy-duty IP65 machine lamp specially designed for CNC equipment. 9.5W high-power COB light source delivers 950lm, 102lm/W high efficiency and Ra＞82, service life up to 50,000hrs. Layered aluminum heat sink, waterproof seal and tempered glass ensure stable performance in oily, dusty workshops. Die-cast aluminum multi-joint arm supports all-direction angle adjustment. Available in DC24V / AC220V and 3 color temperatures, fixed base mounting, 18-month warranty.

Quick Detail

IP65 waterproof & oil-proof, fit harsh machine workshop
9.5W COB, 950lm, 102lm/W, CRI Ra＞82
Isolated driver, PF＞0.9, narrow 32° focused beam
Dual voltage: DC24V / AC200-240V, 3 CCT optional
Multi-joint aluminum arm, flexible multi-angle positioning
Wide temperature tolerance: -20℃~45℃ operation
50,000hrs long life, 18-month factory warranty

Specifications

Parameter	Specification
Model	M2S-B (DC24V) / M2S-C (AC220V)
Rated Power	9.5W
Luminous Flux / Efficiency	950lm / 102lm/W
CRI & PF	Ra＞82, PF＞0.9
CCT Selection	2800-3200K / 4000-4500K / 6000-6500K
Beam Angle	32°
Protection Class	IP65
Light Source	High-power COB chip
Housing	Aluminum heat sink + tempered glass + waterproof ring
Bracket	Die-cast aluminum multi-angle articulated arm
LED Lifespan	50,000 Hours
Working Temp	-20℃ ~ 45℃
Mounting	Fixed base, mounting hole Ø6mm
Standard Wire	0.5m length
Warranty	18 Months

Core Selling Points

IP65 sealed construction, block cutting fluid, dust and moisture
High-performance COB with low light decay, clear focused machining lighting
Multi-section rotatable arm, freely adjust light to any processing position
DC & AC dual voltage + 3 CCT, compatible with all types of machine tools
Optimized heat dissipation keeps lamp surface cool, extend service life

Competitive Advantage

Layered heat dissipation design reduces chip temperature to slow brightness attenuation
Full-range adjustable articulated arm eliminates blind spots for machining operations
Oil & water resistant IP65 structure withstands coolant splashing daily
Isolated power supply, stable output against grid voltage fluctuation
Solid vibration-resistant body, durable for long continuous machine running

Applications

CNC lathe, milling machine, machining center, EDM wire cut, engraving equipment, assembly repair station, precision measuring laboratory.

Package Info

Pack Item	Details
Inner Box Size	470×310×120mm, 1pc per inner box
Outer Carton Size	510×330×620mm, 5pcs per carton
Single Net Weight	1.5 KG
Carton Gross Weight	10 KG
Package Printing	Neutral OEM printing available for bulk orders
